Features & Specs

FEATURES

• 15.0 amp motor uses state-of-the-art circuitry for soft starts and smooth operation
• Full-wave electronic variable speed motor runs at 8,000-22,000 rpm with constant speed under load to ensure a quality finish in all materials
• Rack and pinion depth adjuster and magnified scale and micro-fine bit depth adjuster provides fast and accurate depth settings
• Phosphorous bronze bushings provide a smooth and accurate plunge
• Spindle lock button allows for single-wrench bit changes
• Dust extraction adapter for cleaner work sites
• 1/4" - 1/2" collet capacity for greater versatility
• Guide bushing adapter plate accepts standard guide bushings for template work
• One-piece motor shaft and spindle ensures perpendicularity and accuracy

Specifications

• Amps 15.0 Amps
• Base Dimension 5-5/8 x 6-11/16 in
• Collet Diameter 1/2", 1/4 in
• Depth Stop 3 Stage Turret Stop
• Horsepower 3 HP
• No Load Speed 8,000-22,000 rpm
• Plunge Stroke 2-7/16 in
• Power Tool Type Corded
• Router Base Plunge Base
• Router Type Large Router
• Spindle Lock Yes
• Tool Weight 11.2 lbs

Includes

• 1/4" collet
• 1/2" collet
• Dust Extraction Adapter
• Template guide bushing adapter
• Wrench
